GME XRS-375C4P XRS Connect 4WD Pack

SKU:XRS-375C4P

RRP $899.00
$849.00
SAVE $50.00 (6%)



In Stock


Calculate Shipping

Standard Shipping - $14.95
Shipping with Signature

XRS™ Connect is an Australian Made radio platform designed to be smart, adaptable, and rugged.

Building on the strong heritage of our first generation of XRS™ Connect radios, the all-new XRS™ range once again raises the benchmark for UHF CB Radios, with numerous advancements in technology ensuring GME remains at the cutting-edge of two-way radio communication.

The second generation of XRS™ radios boast a suite of innovative new features including a powerful 3-watt speaker, IP67-rated microphone, high-contrast Colour TFT LCD screen, built-in GPS receiver, Bluetooth Audio connectivity, Noise Reduction technology, and multiple user-customisable buttons.

The XRS™ Connect 4WD Pack pairs the XRS‑375C — a compact metal chassis with a secondary speaker in the base unit — with the heavy-duty AE4704B radome antenna. This combination is ideal for installation in noisy 4WDs and other loud machinery, delivering the perfect solution for users looking to maximise audio output in any conditions.

5 Watt Heavy Duty Compact Design
Professional Grade IP67 Speaker Microphone
3 Watt Speaker Microphone
Anti-Glare, Colour TFT LCD Screen
Scansuite™ - Digital Scanning Technology
Multiple User-customisable Buttons
Bluetooth® - Audio & Data
Built-in GPS Receiver - Location Aware
Noise Reduction Technology
Automatic Power Down
User Updateable Firmware
12/24V Power Input
MIL-STD 810H: Vibration, Shock, Temperature, Humidity
XRS™ Connect - Smartphone Application
XRS™ Connect Features – Voice Playback, Active Mute, Crewtalk, Location Services

(XRS-375C4P)

Product Specifications

GENERAL

Compliant Specification
Meets AS/NZS 4365 for radio communications equipment in the UHF citizen and personal radio service.
Frequency Range TX
476.425-477.4125 MHz
Number of Channels
80
Channel Spacing
12.5 kHz
Operation Mode
Simplex or half Duplex with repeater talk around.
Scanning Speed
25 ms per channel (40 channels per second)
Antenna Impedance
50 Ohms nominal
Nominal Battery Voltage
12 volts DC
Operating Voltage Range
10-16 volts DC
Battery Polarity
Negative Earth
Standard Test Voltage
13.8 volts DC
Overvoltage Protection
30 volts DC max. At 18 volts DC the RF power is reduced, and the words ‘Hi DC’ flash.
Reverse Voltage Protection
Diode Crowbar
Overcurrent Protection
In-line 2 amp fuse
Operating Temperature
-10°C to 60°C
Zones
8 (50 channels per zone)
Scan lists
3

TRANSMITTER

RF Output
5 watts
Spurious Emission
< - 70 dBc
Frequency Error
< ± 1.5 kHz
Modulation
FM
Maximum Deviation
< ± 2.5 kHz at + 20 dB limiting
Transmit Frequency Response
+6 dB per octave 300 Hz to 3 kHz +1-3 dB
Demodulated Audio Signal to Noise
> 45 dB unweighted
Current Consumption
1.5 amps with 50 Ohms termination

RECEIVER

Intermediate Frequencies
38.85 MHz, 450 kHz
Sensitivity
- 122 dBm for 12 dB SINAD unweighted
Selectivity
- 6 dB at + 3.5 kHz, ‑ 60 dB at ± 12.5 kHz
Intermodulation Immunity
-72 dB
Blocking Immunity
-98 dB
Spurious Response Immunity
70 dB
Audio Output Power
3 watts average into 4 Ohms
Audio Signal to Noise
> 45 dB unweighted
Current consumption
< 175 mA muted 750 mA Full volume
Conducted Spurious Emission
< - 70 dBm

MECHANICAL SPECIFICATIONS

External Speaker
3.5 mm mono jack

OTHER

Display type
OLED
