Rockford Fosgate T1000-4AD Power 1,000 Watt Class-ad Full-Range 4-Channel Amplifier

Rockford Fosgate T1000-4AD Power 1,000 Watt Class-ad Full-Range 4-Channel Amplifier

SKU:T1000-4AD

RRP $2,359.00
$2,009.00
SAVE $350.00 (15%)


In Stock
Add To Compare

Calculate Shipping

The Power T1000-4ad is a full-size chassis, 1000-Watt 4-channel amplifier, built on our Class-AD platform offering high fidelity in a full-range configuration.

Overview

The T1000-4ad combines sound quality characteristics of Class-A designs with efficiency of a Class-D in one remarkable package. Superior sound quality is possible through the implementation dynamic switching frequency control. The addition of Constant Power circuitry produces optimized output at a range of impedances. Rockford Fosgate created Class-bd for brute power to run low frequency subwoofers, and now Class-ad offers high fidelity in a full-range configuration.

Key Features

  • 2-Year Warranty
  • 24dB/octave crossover
  • MOSFET power supply
  • MOSFET output stage
  • 4 Gauge power/ground connectors
  • Audiophile grade speaker connections
  • RCA pass-thru outputs
  • 2/4 channel input switch

Warranty

2 years manufacturer's warranty (from Rockford Fosgate's published warranty periods for this product category). In Australia, warranty is handled through the authorised Rockford Fosgate distributor; proof of purchase required.

(T1000-4AD)

2 years manufacturer's warranty (from Rockford Fosgate's published warranty periods for this product category). In Australia, warranty is handled through the authorised Rockford Fosgate distributor; proof of purchase required.

  • 2-Year Warranty
  • 24dB/octave crossover
  • MOSFET power supply
  • MOSFET output stage
  • 4 Gauge power/ground connectors
  • Audiophile grade speaker connections
  • RCA pass-thru outputs
  • 2/4 channel input switch
Model T1000-4AD
Number of Channels 4
Total Power (Sum of Rated Power) 1000 Watts RMS
Rated Power (RMS Continuous Power) 250 Watts x 4 @ 4-Ohm / 250 Watts x 4 @ 2-Ohm / 250 Watts x 4 @ 1-Ohm / 500 Watts x 2 @ 4-Ohm Bridged / 500 Watts x 2 @ 2-Ohm Bridged
Dynamic Power (PVC/PowerCube®) 270 Watts x 4 @ 4-Ohm 0° Res / 327 Watts x 4 @ 2-Ohm 0° Res / 365 Watts x 4 @ 1-Ohm 0° Res / 619 Watts x 2 @ 4-Ohm Bridged / 654 Watts x 2 @ 2-Ohm Bridged
Bridgeable Yes
Frequency Response 20Hz to 20kHz +/-1dB
Input Sensitivity 150 mV to 5 V
Circuit Topology Class Class AD
Efficiency (average) 84.1% @ 4-Ohm / 81.6% @ 2-Ohm / 81% @ 1-Ohm
Total Harmonic Distortion (THD+Noise) 4-Ohm: <1.0% / 2-Ohm: <1.0%
Signal Input Front Channels: 1 RCA pair / Rear Channels: 1 RCA pair / Input Switch: 2CH / 4CH
Signal Output 1 RCA pair
Tone Controls Front Channels: / Treble: 0dB to +12dB @ 12kHz / Bass: 0dB to +18dB @ 45Hz / / Rear Channels: / Treble: 0dB to +12dB @ 12kHz / Bass: 0dB to +18dB @ 45Hz / Function depends upon crossover setting (LP/AP/HP)
Crossover Controls Front Channels: / High-Pass (HP): 50Hz-500Hz @ 24dB/octave Butterworth / Low-Pass (LP): 50Hz-500Hz @ 24dB/octave Butterworth / / Rear Channels: / High-Pass (HP): 50Hz-500Hz @ 24dB/octave Butterworth / Low-Pass (LP): 50Hz-500Hz @ 24dB/octave Butterworth
Remote Controls Optional Remote PEQ / (overrides rear channel built-in Punch EQ)
Visual Indicators Power (Blue LED) / Thermal (Red LED) / Protect (Yellow LED)
Power Wire Gauge 4 AWG
Power Input Connector Block
Speaker Wire Gauge 8 AWG to 16 AWG
Speaker Output Connector Block
Cooling Convection
Operating Voltage 9 - 16 VDC
Recommended Fuse (not included) 150 A
Average Current Draw (13.8V Music) 60 A
Max. Current Draw (13.8V Sinewave) 120 A
Suggested Alternator 75 A
Dimensions (H x W x D) 2.14 x 8.14 x 14.91 (in) / 5.42 x 20.68 x 37.86 (cm)
Shipping Weight 14.45 Lbs. (6.55 Kg.)
