Musway FIVE.100+ 5ch Amplifier

Musway FIVE.100+ 5ch Amplifier

SKU:MUS-FIVE100

In Stock
Add To Compare

Musway FIVE.100+ 5ch Class D Amplifier

  • Start-Stop ready
  • EPS (Intelligent High Level Input Error Protection System)
  • Utilizes 4-fold laminated circuit boards that allows for small size and effectively suppresses EMI (RF) interference which is a must for full range Class D Amplifiers. Passes the difficult EMI European standards.
  • High- and Low-Level Inputs
  • RCA (Low Level) output.
  • Brushed aluminum heat sink and end panels
  • Auto Turn On via DC Offset or Signal Sensing
  • Remote level controller is included in the box

Specifications

OUTPUT POWER RMS @ 13.8v





(CH1 - CH4) 4 x 115w @ 4 Ohms



(CH1 - CH4) 4 x 200w @ 2 Ohms



(CH1 - CH4) 2 x 400w @ 4 Ohms bridged



(CH5) 1 x 225w @ 4 Ohms



(CH5) 1 x 400w @ 2 Ohms



(CH5) 1 x 600w @ 1 Ohms





OUTPUT POWER RMS @ 14.4v





(CH1 - CH4) 4 x 125w @ 4 Ohms



(CH1 - CH4) 4 x 225w @ 2 Ohms



(CH1 - CH4) 2 x 450w @ 4 Ohms bridged



(CH5) 1 x 250w @ 4 Ohms



(CH5) 1 x 425w @ 2 Ohms



(CH5) 1 x 650w @ 1 Ohms





Frequency Range -3dB

4-39000 Hz

Damping Factor

300

S/N ratio

> 107 dB

THD+N

< 0.02%

Input Sensitivity



Low-Level

0,3 - 7,8V

High-Level

0,7 - 15,6V

Channel 1/2



Crossover Modes

Full - HP-Copy

High Pass Filter

50 - 5000 Hz

Channel 3/4



Crossover Modes

Full - HP - LP/BP

High Pass Filter

10 - 500 Hz

Low Pass Filter

50 - 5000 Hz

Channel 5



Subsonic Filter

10 - 40 Hz

Low Pass Filter

40 - 150 Hz

Bass Boost

0 - 18 dB @ 45Hz

Phase Shift

0 - 180

Start-stop capability

8.5V

High Level Input with EPS

Yes

Auto Turn On

Via DC or Signal

Fuse Rating

1 x 125A (external)

Dimensions

295 x 45 x 150 mm

(MUS-FIVE100)
