MATCH UP 8BMW - 8 Channel PnP DSP Amplifier for BMW With S0676 HiFi (E/F Gen) | 9ch DSP

M-Power“ for your BMW HiFi sound system
The MATCH UP 8BMW is the "M Package" for your BMW HiFi sound system! This high performance 8-channel plug & play upgrade amplifier with integrated 9-channel 64 Bit DSP was specifically designed for BMW E & F as well as G30 / G31 (pre-facelift) with HiFi sound system (Option 676). It ensures a significantly more powerful and dynamic audio experience while offering seamless integration. Because a BMW deserves sound that matches its dynamics!

Seamless Integration and Convenient Upgrade Options
With the UP 8BMW, a simple and seamless integration into the BMW HiFi sound system at the original installation location is easily achievable thanks to the included plug & play connection cable and BMW-specific mounting plate. To facilitate further upgrades, it is perfectly designed for combination with other MATCH UPGRADE components for BMW vehicles, such as subwoofers, 2-way systems, and center speakers. With a total of eight amplifier channels and an additional preamp output, individual speaker configurations can be easily realized, thanks to the powerful 9-channel DSP. Two amplifier channels, each delivering 160 W output power at 2 Ohms, provide enough power to boost even large subwoofers. Furthermore, the MATCH UP 8BMW boasts enhanced connectivity, featuring an intelligent 6-channel highlevel input with the ADEP.3 circuit and a MEC slot for system expansions such as Bluetooth® HD audio streaming. It also includes a 1-channel mono line output for connecting external amplifiers like the MATCH UP 1FX and an optical input in SPDIF format with a sampling rate up to 96 kHz. Last but not least, it also comes with our SCP port for optional accessories like the DIRECTOR, CONDUCTOR etc.  

Virtual Channel Processing – The Modern Way of Signal Routing 
The optimal adaptation to existing multi-channel sound systems requires sensible management and configuration of the many DSP channels – so it was no question that the UP 8BMW is also equipped with Audiotec Fischer's innovative virtual channel processing. Especially when front, rear and center systems are split into multi-way systems, conventional routing concepts quickly reach their limits, both in terms of implementation and usability. The multi-stage "Virtual Channel Processing", in conjunction with the recognized user-friendly DSP PC-Tool software makes it easy to map even highly complex system configurations and to freely assign our proprietary FX sound features. Additionally, thanks to its generous number of channels in combination with the optional MEC ANALOG IN module, the UP 8BMW is also a prime example for applications where 1 to 1 routing (IOR) makes sense. 

ACO – Advanced 32 Bit CoProcessor Plattform 
Of course, the UP 8BMW is equipped with our proprietary 32 Bit ACO platform, which doesn’t just take over all control tasks ultra-fast, but also handles a bunch of audio functions: fantastic sound effects such as Augmented Bass Processing or Real Center are implemented as well as a channel-separated Input EQ including Input Signal Analyzer (ISA) for easy analysis and compensation of input signals of OE radios, which already include a sound setup by default. 

DSP PC-Tool 5 feat. TuneEQ – Powerful features for the ultimate sound experience 
Of course, the MATCH UP 8BMW can be easily configured via our professional and exceptionally intuitive DSP PC-Tool 5. The familiar, numerous setting options leave nothing to be desired and guarantee an extremely precise sound adjustment even for complex system configurations. And thanks to the proprietary TuneEQ function for automated frequency response correction, you also save a lot of time when optimizing your sound.

TuneEQ
TuneEQ is an extremely flexible and particularly easy-to-use function for automated frequency response correction. A single measurement per audio channel or channel pair with a suitable measurement microphone (e.g. our MTK1) is sufficient for TuneEQ to independently and precisely adjust the equalizers to the desired reference curve. TuneEQ uses the full function set of the parametric equalizer including center frequency, Q-factor and gain adjustment. And since the highly complex arithmetic operations required for this run in the background, you also save a lot of time when optimizing your sound with TuneEQ.

RealCenter
The “RealCenter” feature is an algorithm, developed by Audiotec Fischer, that emphasizes the music information which is present in both the left and right front channel to create an unique center signal. In contrast to common procedures, in which only the channels are summed up, the intensity of the center signal is also dynamically controlled by the stereophonic informational content of the left and right channel.

Sounds complicated but this effect is astonishing: That means if solely the left or right channel delivers an audio signal, the center channel will not reproduce a signal. In the case of common algorithms, the volume level of the center channel is only reduced by 6 dB (= half volume level). Audiotec Fischer’s “RealCenter” allows a unique, broadened sound staging for both driver and co-driver at the same time! Therefore, the disadvantages of a conventional center channel, such as an intrusive, small sound stage, are things of the past.

Augmented Bass Processing
Audiotec Fischer’s proprietary “Augmented Bass Processing”, consisting of the two revolutionary sound features “Dynamic Bass Enhancement” and “SubXpander”, has been especially developed to dramatically improve the bass reproduction of subwoofers.

The “Dynamic Bass Enhancement” ingeniously combines maximum deep bass and highest sound pressure – regardless of the music style or the tone controls in the head unit. Depending on the input signal, the “Dynamic Bass Enhancement” gains the lower frequency range and varies the cut-off frequency of the subsonic filter. The result is a significantly more powerful and deeper bass response at low and medium volume levels without the risk of overloading the subwoofer neither mechanically nor electrically at high volume levels. It is simply fascinating which bass performance is suddenly possible.

If you want an even lower and “darker” bass reproduction, the “SubXpander” can be additionally activated. Therefore, subharmonic tones are added to the fundamental tones in the frequency range between 50 and 100 Hz.

Product parameters

• Channels: 8 Channel
• Built-in DSP: Yes
• RCA Input: 0 | High-Level only
• High-Level Input: 6x High level
• Power W RMS/ch | 4Ω: 65
• Other Input: Optical
• Class: Pure GD | Ultra HD
• Max Input Sensitivity (V): 11
• THD+N | %: 0.03
• Operational Voltage:
• RCA Out: 1x RCA | Mono
• Product Depth | mm: 153
• Product Width | mm: 130
• Product Height | mm: 46
