JBL Club A1000 Mono Amplifier

Overview

The JBL Club A1000 mono subwoofer amplifier delivers 1000-Watts RMS using a Class D amplifier design to ensure high output and minimum current draw. Speaker-level inputs allow this amplifier to integrate into almost any system, even one using your car's factory radio. You can use the low-pass filter and variable bass boost to maximize the performance of your subwoofer and enclosure, while a phase switch ensures that the bass will blend well with your full-range speakers.

Key Features

• Compact size: The JBL Club A1000 amplifier features a low-profile chassis and a small overall footprint to fit in more vehicles where available space is limited
• Variable crossover and bass boost: Unlike many amplifiers available at similar prices, the JBL Club A1000 features variable electronic crossovers and bass boost circuits allowing for precise system tuning and performance
• Input Level Control: When low-level inputs are used, this control adjusts the input sensitivity between 200mVrms and 2.0 Vrms
• Phase Switch: This switch changes the input phase to inverted or non-inverted. This is especially helpful as part of system tuning based on the enclosure type and location in the vehicle
• Strappable for up to 2,000 watts of power at 4 ohms: Enable to strap two Club A1000 together to double your power, The primary amp will be in absolute control of secondary in terms of the crossover points, the gain and remote level control
• High and low level input: Speaker-level and low-level inputs allow the Club A1000 to integrate with both aftermarket and factory car stereo systems
• Low noise and distortion: The Club A1000 has been engineered using Balanced Differential Inputs to ensure low noise and distortion even at high output levels
• Full on-board protection: On-board circuitry protects the Club A1000 from shorts, high-temperature, overvoltage and undervoltage
• RBC wired remote: The RBC wired remote is an easy installation and can be mounted for convenient volume adjustment from driver's seat
• 600 watts RMS x 1 at 4 ohms (1000 watts RMS x 1 at 2 ohms)
• Class D amp technology
• Variable low-pass filter (32-320 Hz, 12 dB/octave)
• Variable bass boost (0-12dB at 45Hz)
• Phase switch (0, 180 degrees)
• Wired remote level control included
• Preamp inputs and outputs
• Speaker-level inputs (speaker wire-to-RCA adapters included)
• 4-gauge power and ground leads recommended — wiring and hardware not included with amplifier
• 1000w RMS / 2000W MAX

What's Included

• 1 x Club A1000 mono subwoofer car amplifier
• 6 x 35A ATO fuses (3 installed, 3 spare)
• 2 x Bare wire-to-RCA adapters
• 1 x Remote bass control module
• 1 x 16.5' Remote control cable (RJ-25 plugs on both ends)
• 2 x Self-tapping screws for remote (M3 x 15mm)
• 4 x Mounting screws (M4 x 53mm)
• 2 x JBL stickers
• 1 x Owner's manual
