HELIX M SIX DSP - 6 Channel Amplifier | 10ch DSP

That rocks – the new M SIX DSP

The M SIX DSP is more than “just” another six-channel amplifier – rather, despite its small dimensions, you are dealing with a powerful control center that has not less than a total of ten processed DSP channels. In addition, the amplifier delivers plentiful output power with generously 100 Watts RMS per channel into both 4 Ohms and 2 Ohms load.
Finally, its awesome price-performance ratio in combination with the fantastic feature set will ensure bright eyes.

Tonally absolutely HELIX!

Compromises in terms of sound quality have no place in a HELIX product – and that's why the M SIX DSP is equipped with all the finesse for perfect sound. Of course, excellent and separate A/D and D/A converters are just as natural as on the DSP circuit board, which is completely manufactured in Germany, you will find only excellent, separate A/D and D/A converters as well as an extremely powerful DSP from Analog Devices. In addition, the four pre-amplifier outputs with 6 Volts output voltage provide more than enough level to drive any additional amplifier.

Maximum flexibility

Even the internal amplifier section of the M SIX DSP is extremely variable – it can either be operated in 6-channel mode or, thanks to its bridging capability, can also be configured as a 5-channel, 4-channel or even 3-channel amplifier.

Virtual Channel Processing – that´s how signal routing works today

Many DSP channels need to be managed and configured properly – so there was no question that the M SIX DSP is also equipped with Audiotec Fischer's innovative virtual channel processing.

The plus in speed – thanks to ACO

Faster is better – the particularly powerful 32 Bit ACO platform takes over all control tasks and ensures significantly more speed

Compact, cool and absolutely practical

Despite its vast range of functions and huge output power the M SIX DSP presents itself in the same classic, compact HELIX design with distinctive lines like a HELIX M SIX. n.

Product parameters

• Channels: 6 Channel
• Built-in DSP: Yes
• RCA Input: 6x RCA
• High-Level Input: 6x High level
• Power W RMS/ch Bridge: 200
• Power W RMS/ch | 4Ω: 100
• Power W RMS/ch | 2Ω: 135
• Other Input: Optical
• Class: D
• Max Input Sensitivity (V): 20
• THD+N | %: 0.03
• Operational Voltage:
• RCA Out: 4x RCA
• Product Depth | mm: 154
• Product Width | mm: 320
• Product Height | mm: 50
