HELIX Ci3 Subwoofer Amplified Package To Suit Toyota Hilux SR5 Dual Cab

Amplified Subwoofer Upgrade Package

This tested bundle of selected items was created specifically to upgrade the car's sound system using the new Helix technology.

It contains

• subwoofer enclosure to fit
• subwoofer driver
• 1ch mono amplifier
• subwoofer remote control

Upgrade method

• No factory amplifier -> new amplifier integration

Product parameters

• Size: 165mm | 6.5"
• Built-in DSP: No
• Type: No Speakers
• Unit Type: Enclosure | Loaded
• Car Specific: Toyota

PACKAGE ITEMS

HELIX IK S10-SVC2 - 10" 300W RMS Slim Subwoofer | 2Ω

Overview Flat dimensions – deep bass With the shallow HELIX IK S subwoofers, the realization of particularly flat and compact enclosure designs shouldn’t be a problem anymore. Its extremely low installation depth opens up new installation possibilities that do not require making any acoustic compromises at all. Additionally, thanks to the use of large voice coils and its low resonant frequency, the HELIX IK S series delivers an absolutely stunning bass performance, which is in no way inferior to larger dimensioned woofers. Smart down to the very last detail The enormously stiff sandwich paper cone in conjunction with our heavy-duty drive system easily converts amplifier power into powerful sound pressure without any compression effects, while simultaneously demonstrating finesse when it comes to more subtle beats. A special highlight: the magnet system has a threaded hole on the back and thus allows the woofer to be fixed to the back panel of the enclosure. Since every millimetre of depth counts in flat constructions, enclosure vibrations are effectively reduced – even with thin walls. "All inclusive" for self-made enthusiasts In addition to the high-quality connection terminal with gold-plated screw terminals, a solid protective grille and gasket are also included. For optimal bass performance in DIY installations, you can find recommendations for sealed and vented enclosures with all parameters such as net volume, port tuning frequency or DSP settings in our technical data sheet. Features Chassis with particularly low installation depth – optimized for compact and shallow enclosure constructions 1 x 2 Ohms single voice coil A magnet system with a threaded hole on the back – allows screwing to the back panel of the enclosure for stabilization and reduction of enclosure vibrations Extremely stiff sandwich paper cone Long-excursion rubber surround for the highest mechanical rating Rugged magnet cover with HELIX lettering for perfect magnet protection Enclosure connection terminal, grille and gasket included in delivery Technical data Power handling RMS / max. P 300 / 600 Watts Impedance Z 1 x 2 Ω DC resistance Re 2.0 Ω Resonance frequency Fs 37 Hz Mechanical Q factor Qms 7.61 Electrical Q factor Qes 0.54 Total Q factor Qts 0.51 Compliance Cms 150 μm/N Equivalent air volume Vas 26 L Force factor B*I 10.1 Tm Sensitivity SPL 93.0 dB @ 2.83V / 1m87.0 dB @ 1W / 1m Cone area Sd 353 cm² Moving mass Mms 119 g Cone material Sandwich paper cone Mechanical resistance Rms 3.7 kg/s Voice coil diameter ø 50.8 mm Voice coil winding height 18 mm Max. linear excursion Xmax +/- 6.0 mm Outer diameter ø 262 mm / 10.31" Installation diameter ø 229 mm / 9.01" Installation depth 84,5 mm / 3.33" Recommended enclosure volumes Sealed box Net volume 14 L Lower limiting frequency (-3dB) 46 Hz Recommended DSP settings Recommended "self-define" highpass filter with 45 Hz cut-off frequency and Q = 1.3;additional EQ filter 100 Hz / Q = 1.0 / -3 dB Vented box Net volume 16 L Port diameter ø 70 mm / 2.76" Port area 38 cm² Port length 38 cm / 14.96" Port tuning frequency Fb 37 Hz Lower limiting frequency (-3dB) 39 Hz Recommended DSP settings Recommended "self-define" highpass filter with 37 Hz cut-off frequency and Q = 1.2;additional EQ filter 95 Hz / Q = 0.7 / -3 dB Scope of delivery 1 x Subwoofer HELIX IK S10-SVC21x Grille1 x Gasket1x Enclosure connecting terminal1 x Data sheet
Read more

BASSER Toyota Hilux 2015-2023 - 10" Premium Fit-Box Subwoofer MDF Enclosure 15L

Overview WATCH THE SUBWOOFER IN ACTION HERE. Introducing our slimline direct-fit sealed subwoofer enclosure specifically designed for Toyota Hilux models from 2015 to 2023. This enclosure fits seamlessly behind the rear seats, providing a perfect space for a shallow-mount 10" / 25cm subwoofer (woofer not included). With a volume of 15 litres, it offers optimal bass performance without sacrificing valuable space in your vehicle. Upgrade your audio experience in your Toyota Hilux with our custom-fit subwoofer enclosure. Material: Solid MDF design, premium black carpet, the box has flanges for easy mounting. The mounting locations have been carefully designed with MDF flanges to ensure that bolts or screws do not extend beyond the inner sheet metal brackets, preventing any protrusion through the rear wall to the outside. Speaker terminal included. See the dimensions in the table below and in the photos attached. Fit-Box subwoofer enclosure is a perfect way to improve bass in the car. By adding to the vehicle it takes up a little space and doesn't interfere with regular car use. Boxes are made to host the most common sizes of subwoofers and simultaneously provide great bass in the car. Fit-Box enclosures are manufactured in Europe. In their production, the best quality MDF is used with the overlapping stack-up method. This way, any shape of the enclosure can be achieved with significantly increased rigidity. Also, the carpet work is perfectly lined up. Therefore, even after years, the product looks brand new as a result of its high quality. With Fit-Box enclosures your subwoofers will play as the manufactured intended to. Installation Important Fitment Notice – Please Read Before Purchasing Before purchasing a Fit-Box enclosure, it is essential to confirm compatibility with your specific vehicle model. Some cars may have varying equipment configurations or factory-installed modules located in the mounting area. It is the buyer’s responsibility to ensure there is sufficient space for proper installation. If you’re unsure, please contact us prior to purchase or send a clear photo of your boot space. Our team is happy to help confirm fitment in advance. In rare cases, minor modifications such as trimming, drilling, or incising non-structural vehicle elements may be necessary for a proper fit. No changes to the vehicle’s chassis or structural components are ever required. Fit-Box installation should always be carried out by a qualified professional. We strongly recommend having the installation performed by an experienced car audio specialist, such as the team at SOUNDTECH Car Audio. Important:Returns or refunds will not be accepted for enclosures that do not fit due to incorrect measurements or unverified assumptions. As outlined in our Refund & Shipping Policy, Basser enclosures are not eligible for refunds based on fitment issues. Technical data Board MDF Fabric Black Melange Speaker size (not included) 10"/25cm Mounting hole diameter (mm) 232 Subwoofer depth (mm) 100 MAX magnet diameter (mm) 140 Volume closed enclosure (litres) 15 Weight (kg) 5,7
Read more

MATCH UP 1FX - 1 Channel Compact Digital High-Power Amplifier | 1Ω Stable

Overview Power. Precision. Control: MATCH UP 1FX Exceptionally compact and powerful, this highly efficient high-fidelity Class D amplifier delivers exceptional sound quality in combination with an impressive output power of up to 1000 Watts. The immense power drives even high-performance subwoofers to peak performance and makes the UP 1FX the perfect companion for all HELIX and MATCH subwoofer chassis and enclosure subs. Perfect integration without compromises Simple and uncompromising – the MATCH UP 1FX offers the ideal solution for upgrading factory subwoofer amplifiers, thanks to the integrated active crossover and high power stereo highlevel input with ADEP.3, max. 32 V input voltage, and signal summing. The mono RCA / Cinch input as well as the DirectDSP function make it the perfect complement to our MATCH UPGRADE DSP amplifiers. Furthermore, the power supply with Start-Stop capability and extended input voltage range of up to 18 V enables the amplifier to be used in modern electric vehicles. Pure sound enjoyment Despite its enormous output power, the MATCH UP 1FX is more than just a subwoofer amplifier. Its special construction, excellent signal-to-noise ratio, and low distortion guarantee pure audio enjoyment. Therefore, the UP 1FX is the perfect partner for heavy-duty mid-woofers in audiophile system concepts. In addition, the innovative DirectDSP function allows bypassing the internal crossover and routes the input signal unfiltered to the output stages of the amplifier, delivering a sound that even exceeds the expectations of discerning music enthusiasts. Compact dimensions for flexible installation possibilities Contrary to its impressive power output, the 1-channel subwoofer upgrade amplifier comes in the same extremely compact dimensions as our UP 8DSP amplifier. This allows space-saving installations, even in vehicles with limited space. Features High-fidelity amplifier with exceptional sound quality and massive output power of up to 1000 Watts Advanced Class D concept for excellent power-to-size ratio Ideal for upgrading factory subwoofer amplifiers thanks to integrated, active crossover and high power stereo highlevel input with signal summing, up to 32 V RMS input sensitivity and ADEP.3 circuit Start-Stop capable power supply with extended input voltage range up to 18 V – ideal for modern EV vehicles DirectDSP function – input signal bypasses the integrated, active crossover and is routed unfiltered to the output stage of the amplifier Clipping LED for easy and fast gain adjustment Compact design for space-saving installation Remote control for volume control of the supbwoofer optionally available The perfect companion for MATCH UPGRADE amplifiers thanks to mono RCA input Special Features Smart highlevel input ADEP.3 Modern, factory-installed car radios incorporate sophisticated possibilities of diagnosing the connected speakers. In particular the latest generation of car radios are equipped with additional monitoring functions so that failure messages and loss of specific features (e.g. fader function) quite often appear if a common amplifier will be hooked up – but not with the UP 1FX.The new ADEP.3 circuit (Advanced Diagnostics Error Protection, 3rd Generation) avoids all these problems without loading the speaker outputs of the OE radio during high volumes unnecessarily. Start-Stop capability The switched power supply of the MATCH UP 1FX assures a constant internal supply voltage even if the battery’s voltage drops to 6 Volts during engine crank. If the supply voltage drops below 10.5 Volts for more than five seconds the amplifier goes to “Protect mode” (Status LED lights up red) in order to avoid any further discharge of the car’s battery. Technical data Power RMS - @ 4 Ohms 1 x 350 Watts - @ 2 Ohms 1 x 600 Watts - @ 1 Ohm 1 x 900 Watts* - bridged @ 4 Ohms - - bridged @ 2 Ohms - Max. output power Up to 1000 Watts RMS @ 1 Ohm Amplifier technology Class D Inputs 1 x RCA / Cinch2 x Highlevel speaker input1 x Remote In1 x Remote control input Input sensitivity RCA / Cinch 0.5 - 3 Volts or 1 - 6 VoltsHighlevel 2.5 - 16 Volts or 5 - 32 Volts Input impedance RCA / Cinch 8.6 kOhms Input impedance highlevel 9 - 33 Ohms Outputs 1 x Speaker output Output voltage RCA / Cinch - Signal converter for digital input - Frequency response 10 Hz - 25,000 Hz Bass boost - Highpass - Lowpass 50 Hz - 250 Hz adjustable (can be turned off) Bandpass - Subsonic 15 Hz (can be turned off) Phase - Slope high- / lowpass 12 dB Slope subsonic / lowpass 12 dB Signal-to-noise ratio digital input - Signal-to-noise ratio analog input 108 dB (A-weighted) Distortion (THD) 0.002 % Damping factor 160 Operating voltage 10.5 - 18 Volts (max. 5 sec. down to 6 Volts) Idle current 1050 mA Fuse 2 x 30 A LP-Mini-fuse (APS) Power rating DC 12 V ⎓ 80 A max. Ambient operating temperature range -40 °C to +70 °C Additional features Active, adjustable crossover, Start-Stop capability, highlevel input with automatic turn on function, ADEP.3, DirectDSP function Dimensions (H x W x D) 46 x 130 x 153 mm / 1.81 x 5.12 x 6.02" Scope of delivery 1 x Amplifier MATCH UP 1FX1 x Mounting plates and material1 x Instruction manual
Read more

HELIX SRC - Subwoofer Remote Control

Overview The universal subwoofer cable remote control SRC is compatible with all HELIX amplifiers which have a remote control input and allows adjusting the volume of the connected subwoofer. As soon as the remote control is connected to the device it will be activated automatically. On all 4-channel amplifiers it solely affectes the output channels C & D if those are configured to "bandpass" mode. Features Compact and easy to install subwoofer cable remote control Also useable for all 2- and 4-channel HELIX amplifiers Cable length 5.00 m Mounting material included in delivery Technical data Control elements 1 x Rotary knob Cable length 5.0 Meter Compatibility HELIX C ONE P TWO G FIVE G FOUR G TWO G ONE M ONE M ONE X D FOUR D ONE MATCH UP 1FX Scope of delivery 1 x Cable remote control SRC1 x Connection cable 5.0 m 1 x Mounting material
Read more
