DNA Car Audio RV74B-AHD 7 Inch Analog High Definition (AHD) LCD 4 Channel Quad Rearview Screen

7 Inch Analog High Definition (AHD) LCD 4 Channel Quad Rearview Screen

This high resolution 4 Channel quad picture AHD monitor is ideal for multiple camera applications with 11 different image views, from full screen viewing and multiple split screen viewing.
Includes front panel touch buttons with a large removable sun visor and is ideal for Caravans, Buses and Truck installations where a large viewing screen or multiple camera viewing is required.
AHD supports 720P, 960P and 1080P video resolutions.

Screen:
7 Inch AHD display
Aspect Ratio: 16:9
Video System: (AUTO) PAL & NTSC
Resolution: 1024 (RGB) x 600 Pixel
4 HD Camera Inputs with 4 triggered inputs for each camera
Supports 720P @ 25/30, 720P @ 50/60, 1080P @ 25/30
Supplied with 6 metre 4 pin to 4 pin extension cable for connection between screen and camera
Dash mountable with U shaped bracket
Screen sun visor
Illuminated touch front panel buttons
4 Pin water-resistant lockable camera connections
IR remote
Image options: UP/Down and Left/Right (mirror)
Operating Temperature: 0°C /+60°C
Operating Voltage: 12V to 24V DC (+/- 10%)
Current Consumption: 5W
Size: 180mm W x 121mm H x 24mm D
Packaging:  Display box

Important information:
AHD cameras WILL NOT work on non-AHD screens.
Non-AHD cameras WILL work with AHD screens.
