Calibre 24VR 24V to 12V 10A Voltage Reducer with Accessory Outputs

Calibre 24VR 24V to 12V 10A Voltage Reducer with Accessory Outputs

SKU:24VR

$99.00


Sold Out
Notify Me
Add To Compare

Calculate Shipping

Standard Shipping - $9.95
Shipping with Signature

Calibre 24VR 24V to 12V 10A switchmode reducer with ISO connectors and fly leads - switched acc, reverse and illumination outputs for 12V gear in 24V vehicles.

Overview

The Calibre 24VR lets you install 12V devices such as a head unit in a 24V vehicle. It is plug-and-play with ISO connectors, and three switched accessory outputs (acc, reverse and illumination) let you control up to three 12V accessories. It can also connect to 24V headlight and signal-light circuits.

Key Features

  • 16-32V in, 12V 10A continuous out
  • ISO connectors plus fly leads
  • 3 switched outputs: acc, reverse, illumination
  • Over-current, reverse polarity and thermal protection
  • 94% efficient
  • -40 to +85 deg C

What's Included

  • 24VR reducer
  • ISO connectors
  • Fly leads

(24VR)

2 Years

  • 16-32V in, 12V 10A continuous out
  • ISO connectors plus fly leads
  • 3 switched outputs: acc, reverse, illumination
  • Over-current, reverse polarity and thermal protection
  • 94% efficient
  • -40 to +85 deg C

Specifications

Brand Calibre
Input Voltage 16-32V DC
Output Voltage 12V DC
Rated Current 10A continuous
Standby Current 3mA
Accessory Inputs Acc, reverse, illumination (16-32V DC)
Accessory Outputs Acc, reverse, illumination (100mA each)
Protection Over current 14A (constant), 250mA (accessories), reverse polarity, thermal
Operating Temperature -40 to +85 deg C
Efficiency 94% at max load
Dimensions 76W x 83D x 36H mm (76 x 59 x 36mm excl. mount)
